LOCATION
To ensure correct ventilation for the motor and
controls the following minimum installation
clearances are to be adhered to:
Top 200mm / 8”
Rear 25mm / 1”
Left-hand side 25mm / 1”
Right-hand side 25mm / 1”
OVEN INTERNAL DIMENSIONS
Width 695 mm / 27
3
/
8
”
Height 285 mm / 11
1
/
4
”
Depth 505 mm / 19
7
/
8
”
Oven Volume 0.10 m³ / 3.5 ft³
OVEN RACK SIZE
Width 660 mm / 26”
Depth: 460 mm / 18”
ELECTRICAL SUPPLY SPECIFICATION
OPTIONS
208-220V ac, 50/60Hz, 14.4A, 3.0kW @ 208V
230-240V ac, 50/60Hz, 12.5A, 3.0kW @ 240V
ELECTRICAL PLUG SPECIFICATION
REQUIREMENTS
Australia 3-pin 250V 15A, AS/NZ 3112
Canada 3-pin 250V 15A, NEMA 6-15
New Zealand 3-pin 250V 15A, AS/NZ 3112
United Kingdom 3-pin 250V 13A fused, BS
1363A
United States 3-pin 250V 15A, NEMA 6-15
Other Countries 3-pin 250V 13A minimum,
type to meet country
standards
