TABLE OF FIGURES
®
®
Trueprep AUTO v2
®
Figure 1: TheTrueprep AUTO v2 Top View, with cartridge holder 5
shown in the front panel
®
Figure 2: The Trueprep AUTO v2 device Back Panel with Reagent Pack of the 6
®
Trueprep AUTO v2 Universal Cartridge Based Sample Prep Kit
®
Figure 3: Disposable Trueprep AUTO v2 cartridge for sample processing 6
Figure 4: Low battery LED glowing red 7
Figure 5: The Charging Port in right hand side of the 8
®
Back Panel of the Trueprep AUTO v2
Figure 6: The Blue Charging LED Indicator Glowing 8
Figure 7:
Figure 8:
Figure 9: Reagent Reset Card for 50Tests Pack size 10
Figure 10: The cartridge holder opened after eject button is pressed 11
Figure 11: Cartridge being placed in cartridge holder 12
Figure 12: Cartridge placed in cartridge holder in correct orientation 12
Figure 13: Replaceable tray in cartridge holder 13
Figure 14: Removal of Replaceable Tray from cartridge holder 13
Figure 15: Replacement of discarded Replaceable tray with new 14
®
The Trueprep AUTO v2 Back Panel, with tubing and caps for plugging in
®
reagent bottles from the Reagent Pack of 25T pack size of the Trueprep
AUTO Universal Cartridge Based Sample Prep Kit
9
®
The Trueprep AUTO v2 device Back Panel with Reagent Pack (50T) of
®
the Trueprep AUTO v2 Universal Cartridge Based Sample Prep Kit
9
