Molbio Trueprep AUTO v2 - Installation and Environmental Requirements; Installation Precautions; Environmental Requirements; Device Specifications

4
2 Installation
2.1 Installation Precautions
®
 Do not install the Trueprep AUTO v2 next to instruments that may cause
vibrations or electromagnetic interference.
®
 Do not store the Trueprep AUTO v2 in the path of direct sunlight or use it close to any
radiating or heating apparatus, such as a conventional oven, hot plate or infrared lamp.
®
 Do not store the Trueprep AUTO v2 in an atmosphere of potentially explosive liquids,
vapors and gas.
®
 Always place the Trueprep AUTO v2 on a flat surface in an upright position.
2.2 Environmental Requirement
®
The Trueprep AUTO v2 has been designed to operate safely within the following environment
specifications:
 Room temperatures ( between 15°C to 45°C )
 Relative Humidity (RH) between 10% –90% (non-condensing)
 The unit should be stored on a flat, dry surface.
3 Specifications
“ AUTO v2 complies with the emission and immunity requirements described in IEC 61326
®
Trueprep
series”.
4 Precautions
®
 Check for Low Battery before using the Trueprep AUTO v2 (see section 7.1)
 Insert and remove the cartridge gently from the holder, use of excessive force could damage
it.
 Do not spill liquids inside the cartridge holder
 Do not perform an extraction in the presence of reactive vapours (e.g., from sodium
hypochlorite, acids, alkalis or aldehydes) or dust.
Proprietary matrix-based extraction
Fully Automatic
2 line alphanumeric LCD
Rechargeable Lithium Ion Battery Pack 7.4 V, 8.7 Ah
External AC/DC adaptor: Input 1.5A, 100/240V, 50/60 Hz;
Output 10V, 4.5A
2.75 kgs
215 x 235 x 115 mm
Proprietary firmware
Temperature 15 - 45°C, RH: 10 -90%
Principle
Operation
Display Screen
Power
Weight
Size
Software
Operating environment
®
Trueprep AUTO v2 Device
®
®
Trueprep AUTO v2
