Molecular Devices ImageXpress Pico Calibration Kit Guide

5063669 E 31
Appendix A: Optional Parts and Accessories
This section describes the items available from Molecular Devices for the ImageXpressPico
system, including the following:
Objectives, see below
Filter Cubes, see below
Accessories, see page 32
See Obtaining Support on page 6 for details on contacting Molecular Devices.
Objectives
The following Leica objectives, which are available from Molecular Devices, are compatible
with the ImageXpressPico system:
Objective Part Number Mag.
Numerical
Aperture (NA)
Working
Distance
Corr.
Collar
PL FLUOTAR 4x/0.13 5064345 4x 0.13 17.0 mm No
HC PL FLUOTAR 10x/0.32 5064346 10x 0.32 11.13 mm No
HC PL FLUOTAR 20x/0.40 5064347 20x 0.4 7.45 mm No
HC PL FLUOTAR L 40x/0.60 CORR 5064348 40x 0.6 3.0 mm Yes
HC PL FLUOTAR L 63x/0.70 CORR 5064349 63x 0.7 2.0 mm Yes
CAUTION! To prevent damaging both the instrument and your sample, do not use
any other objectives with the ImageXpressPico system.
Filter Cubes
The following filter cubes, which are available from Molecular Devices, are compatible with
the ImageXpressPico system:
Filter Part Number Excitation Emission Dichroic
DAPI 5064350 370/40nm 450/60nm 410 nm
FITC 5064351 465/40nm 525/30 nm 500 nm
TRITC 5064352 530/45nm 594/40nm 560 nm
Cy5 5064353 630/40nm 695/45nm 655 nm
Texas Red 5069939 560/50 nm 645/75 nm 595 nm
CFP 5069940 400/30 nm 480/40 nm 475 nm
A
