MX123 Connection System User Manual - AS-34566-001 18
D. Wire Dressing Method
 After inserting a terminal, bend the wire as close to the grommet cap as
possible and position as shown below. Continue populating terminals as
necessary.
Section 3: Harness Assembly Instructions
1 2
3
4 5
6
