MX123 Connection System User Manual - AS-34566-001 19
* Molded-in or single grommet seal plugs are used to seal unused circuit locations.
NOTE! Molded-in grommet seal plug knockout patterns will vary based on
application specific circuit locations. Single grommet seal plugs may still need to
be used to seal circuits without molded-in seal plugs.
Section 3: Harness Assembly Instructions
E. Grommet Seal Cover - Knockout Patterns
Cavities Open For Circuits Molded-in grommet seal plugs
