MX123 Connection System User Manual - AS-34566-001 33
Section 5: Service Instructions
A. Harness Connector Removal From Module (continued)
 While pushing forward on the lever, grip the back of the harness and evenly
pull straight upwards and away from the module (Fig. 5-4).
Fig. 5-4
2
1
