Page 6 of 24
BM03 - English - Molift Partner 230/255 - Rev. G/ 02/2008
Technical data
Weights: 40 kg / 88 lbs (excl. battery)
Weight disassembled:
Chassis: 20 kg / 44 lbs
Column: 14 kg / 31 lbs
Liftingarm/suspension: 6 kg / 13 lbs
Battery: 1,5 kg / 3,3 lbs
Material:
Steel, aluminium and composite plastic
Motor:
Lifting motor: 24 V DC
Leg spreading motor: 12 V DC
Battery:
26,4 V NiCd 1,9 Ah, 20 A, ATO Fuse
Battery charger:
Mascot type 2215,10-22 cells NiCd/NiMH
Protection:
IPX4
Safe Working Load (SWL):
Partner 230: 230 kg / 507 lbs
Partner 255: 255 kg / 562 lbs
Lifting range:
1275 mm
Turning diameter:
1400 mm
Lifting speed:
30 mm/sec (with 75 kg / 165 lbs)
Sound level, max A-weighted sound power level:
L
WA
= 62,3 dB
Operating forces:
Buttons on handcontrol: 3,4 N
Number of lift with fully charged battery:
75 lifts (75 kg / 165 lbs, 50 cm)
Measurements:
1325 x 700 x 1902 mm (LxBxH)
Measurements in illustrations below are in millime-
tres.
