75
MONTEREY
BOATS
Electrical System
Cockpit Lights
Activates the lights that illuminate the cockpit and
bow seating area. Also activates the stern storage
compartment and engine compartment lights on
some models.
Digital switches will alternate light color each time
the button is pressed.
Arch Lights
Activates the lights in the arch that illuminate the
cockpit, bow seating area, stern storage compart-
ment, helm storage compartment and engine
compartment.
Digital switches will alternate light color each time
the button is pressed.
Engine Room Lights
Activates the 12-volt lights in the engine com-
partment.
Underwater Lights
Activates the underwater lights in stern below the
water line.
Blower
This switch supplies electrical current to the blower
that provides ventilation to the engine compart-
ment.
OPEN THE ENGINE COMPARTMENT HATCH, INSPECT THE
Engine Hatch (some models)
Conventional engine hatch switches are an ON
-OFF-ON momentary switch that controls the
electric actuator for the engine hatch. Press the
top of the switch to raise engine hatch. Press the
bottom of the switch to close hatch. The switch
automatically returns to the OFF position when it
is released.
Digital switch panels have a separate momentary
switch for hatch up and hatch down.
Bilge Pump
Manually activates the aft bilge pump which is
The pump moves water out through the thru-hull
switch in the “ON” position.
Fwd Bilge (some models)
Manually activates the forward bilge pump located
in the forward bilge. The pump moves water out
activated by an automatic switch that is activated
whenever the batteries are connected. This pump
will run as needed whenever the water in the bilge
accumulates high enough to cause the switch to
activate and turn off when the water is removed.
NOTICE:
The bilge pumps will start automatically when
-
vate the electronic water level switch built
into each pump. The automatic switch is
protected by a circuit breaker located in the
battery switch panel and is always supplied
current when the batteries are connected.
Refer to the Drainage Systems chapter for
more information on the bilge pump system.
Windlass Switch
This switch controls the optional windlass which
is mounted to the deck directly above the rope
locker. It is protected by a circuit breaker of the
type and rating recommended by the windlass
manufacturer that is located in the cabin breaker
panel. There could also be a switch to control
the windlass in the winch compartment next to
the windlass.
Digital switch panels have a separate momentary
switch for windlass up and windlass down.
Wipers
Activates the windshield wipers.
Water System
Activates the fresh water pump. The pump is the
pressure demand type. The pressure switch built
into the pump automatically controls the water
pump when the system is activated and properly
primed.
Horn
Activates the boat horn.
Digital switch panels will have a horn button on
each page for safety purposes.
