04
Top Panel
01
MASTER
Independent volume controls for XLR, headphones and 1/4” jack outputs
LCD screen
5-inch TFT monitor displays the GUI
02
1 – 5
Adjust individual parameters in the GUI
03
04
SELECT
Rotate / Press to make selections within the GUI
<< >>
Scroll parameter pages left and right in the GUI
05
06
EXP1 / EXP2 LED
Displays the ON/OFF status of the EXP pedals
EXP1: Built-in expression pedal. Press forward in the toe-down position to toggle on/off
EXP2: LED will illuminate when an external expression pedal is detected at the EXP2 input
SCREEN MENUS
DISPLAY: Toggles between FOOTSWITCH VIEW and SIGNAL CHAIN on the GUI home-screen
Press to return home from other screens
GLB-EQ: Global EQ settings menu
CTRL: Configure, assign and customize footswitch settings
SYSTEM: Global system settings menu
SAVE: Save PRESET menu
EXP: EXP1 and EXP2 settings and calibration menu
07
EXP 1
Built in expression pedal
08
CTRL 1 – 4
FS MODE 1: Assign functions via CTRL button
FS MODE 2: Assign functions via CTRL button / selects preset from top column after ↑ / ↓
09
A , B , C , D
FS MODE 1: Selects corresponding preset A , B , C , D
FS MODE 2: Assign functions via CTRL button / selects preset from bottom column after ↑ / ↓
A + B = TUNER B + C = LOOPER
10
↑ / ↓
Preset BANK UP / BANK DOWN footswitches
11
EFFECT BLOCK
Press to enter effect block edit screen
Press to toggle effect block on/off
LED displays the on/off status of the effect block
12
