06
Back Panel
13
AUX IN
Connect external media devices for audio playback1/8” stereo jack
INPUT
Instrument input ¼” mono jack with Guitar/Line level switch
OUTPUT
2 x ¼” mono jack
L = MONO output L + R = STEREO output
XLR OUT
2 x Balanced XLR output with Ground lift switch
L = MONO output L + R = STEREO output
USB
USB Type-B
Connect to computer to record direct digital audio
Interface with official MOOER software to edit and import/export presets
Update firmware
Cable tidy
Loop the cable from your power supply to avoid accidental disconnection
DC IN
Connect GE300 power supply
PHONES
Dedicated headphone output ¼” stereo jack
14
15
16
17
18
19
I/O
Power ON/OFF switch
20
MIDI IN / OUT
21
22
SEND/RETURN
Stereo effects loop
L = MONO loop
L + R = STEREO loop
SEND = 2 x ¼” mono jack output
RETURN = 2 x ¼” mono jack input
23
EXP2
External expression pedal input
This can also be used as an external switching output.
24
