PARALLEL
VCW VCF
VCWVCF
Both VCW and VCF get their
input from the MIXER.
VCW input is from MIXER;
VCF input is from VCW output.
VCF input is from MIXER;
VCW input is from VCF output.
ORDER
This reroutes the internal signal routing to VCW and VCF paths:
