Moog LABYRINTH - Global Settings

46
By holding BUFFER + RESET while Labyrinth is booting up, users can enter a Global Settings Mode.
Only two Global Settings exist which are indicated by a corresponding LED in the BITS section.
By pressing LENGTH (1) (-) and BIT FLIP (1) (+), users may select a setting. The currently selected
setting will pulse at a slow rate.
By pressing BIT SHIFT (1) and BIT SHIFT (2), users may change the value of the currently selected
setting. The color of the LED indicates its value. See the table below for what the colors mean for each
setting. In all cases, red is the default value.
By pressing BUFFER, users may save the currently selected settings and return to normal operation.
All LEDs will flash green three times to indicate a successful save.
GLOBAL SETTINGS
Setting (SEQ, Bit) Description RED Setting GREEN Setting
1, 1
1, 2
RESET IN
jack behavior
CV Out Polarity
+5 Volts at RESET IN Jack resets
sequencer to bit 1
Bipolar: CV Outs generate voltages
between +/- 5V centered at 0V
+5 Volts at RESET IN Jack resets
sequencer to bit 1 AND recalls the Buer
Unipolar: CV Outs generate voltages
between 0V +5V centered at 0V
