Moog LABYRINTH - Sequencer Button Combos

37
Combo Function Description
LED Eect/
Feedback
SEQ Length Reset
Rotate Reset
CV Quantize -
CV Quantize +
Chained Mode Oset
Chained Oset Reset
Buer Save
Sequence Clear
MIDI Clock Division -
MIDI Clock Division +
MIDI Channel Select
Global Settings Select
Shift WRITE head (1,2)
Reset WRITE head (1,2)
LENGTH (1,2)
+ RESET
BIT SHIFT (1,2)
+ RESET
BIT SHIFT (1,2)
+ ADVANCE
HOLD BUFFER 1 SEC
HOLD BUFFER
+ RESET 1 SEC
HOLD CHAIN SEQ
ON STARTUP
HOLD BUFFER +
RESET ON STARTUP
BIT SHIFT (2)
+ LENGTH (2)
BIT SHIFT (2)
+ BIT FLIP (2)
BIT SHIFT (1,2)
+ ADVANCE + RESET
BIT SHIFT (1)
+ LENGTH (1)
BIT SHIFT (1)
+ BIT FLIP (1)
BIT SHIFT (2)
(IN CHAINED MODE)
BIT SHIFT (2) + RESET
(IN CHAINED MODE)
Green LEDs flash to show
new sequence length.
All green LEDs light; red LED
shows new quantization
mode (1–16).
All green LEDs light; red LED
shows new quantization
mode (1–16).
All yellow LEDs light; red
LED shows new MIDI
Clock division (1–16).
All yellow LEDs light; red
LED shows new MIDI
Clock division (1–16).
All red LEDs light; green LED
shows current MIDI channel. All
green LEDs are OMNI. CHAIN SEQ
LED flashes to indicate current
mode. All green LEDs flash three
times on confirm.
See “Global Settings” section of
this manual for more. CHAIN
SEQ LED flashes to indicate
current mode. All green LEDs
flash three times on confirm.
All green LEDs flash three
times if success.
None
None
None
None
None
None
Resets length of SEQ1 or
SEQ2 to 8.
Rotates all bits of SEQ1
or SEQ2 back to
original position.
Shifts WRITE head
forward 1 bit in relation
to PLAY head.
Returns WRITE head to
PLAY head position.
Decrements current
quantization mode by 1.
Increments current
quantization mode by 1.
Moves SEQ2 PLAY head once,
changing oset between
SEQ1 and SEQ2 PLAY heads
(in chained mode).
Snaps SEQ2 PLAY head to
SEQ1 PLAY head,
synchronizing both SEQs
(in chained mode).
Saves bit states, quantization
mode, WRITE head osets,
and CHAIN SEQ mode status
to memory.
Clears all bit states,
quantization mode, and
WRITE head osets in current
sequence.
Decrements current MIDI
clock division by 1.
Increments current MIDI
clock division by 1.
Boots into MIDI Channel Select.
Press BIT SHIFT (1) to incre-
ment, BIT SHIFT (2) to decre-
ment, and CHAIN SEQ to
confirm and return to normal
operation. Default is OMNI.
Boots into Global Setting
Select. See “Global Settings”
section of this manual for
more.
SEQUENCER BUTTON COMBOS
