Voltage-Controlled BLEND between the VCW and VCF in parallel
or series congurations, a Voltage-Controlled Amplier (VCA)
for each audio path, and two Envelope Generators (EGs) with
variable DECAY
ENVELOPE/VCA CONTROLS
PAGE 34
2-pole state-variable Voltage-Controlled Filter (VCF)
allowing for blending between lter responses,
voltage control of VCF CUTOFF frequency, and
manual RESONANCE control
FILTER
PAGE 30
32-point modular patch bay with 12
outputs and 20 inputs
PATCH BAY
PAGE 39
