moon 110LP - Specifications

110LP MOON Series
10
Specifications
Circuit Layout Mirror-image symmetrical circuit
Single-ended inputs 1 pair (RCA)
Input Impedance - Adjustable
100 and 47kΩ
Input Capacitance - Adjustabl 0 and 100pF
Gain Level – Adjustable 40 and 60dB
Single-ended outputs 1 pair (RCA)
Input overload @ 40dB gain 45mV RMS @ 1kHz
Input overload @ 60dB gain 4.5mV RMS @ 1kHz
Signal-to-noise Ratio (full scale @40dB gain) 104dBr
Signal-to-noise Ratio (full scale @60dB gain) 87dBr
Maximum Output (1kHz @ 10KΩ)s
3.0 Volts
Frequency Response
20Hz - 20kHz (± 0.5dB)
Crosstalk @ 1kHz -97dB
Intermodulation Distortion < 0.009%
THD (20Hz - 20kHz) < 0.001%
Power Consumption @ idle 2 Watts
AC Power Requirements 120V / 60Hz or 240V / 50Hz
Shipping Weight 2.5lbs / 1.1 Kgs.
Dimensions (W x H x D, inches / cm) 5.0 x 2.9 x 6.5 / 12.7 x 7.4 x 16.5
