29
Rev. 1.0
10/21/2018
SSDC-D/IP Hardware Manual
400-820-9661
Connecting a sourcing output to load
Connecting a sourcing output to PLC's input
Driving a relay
Connecting a sinking output to PLC's input
Y1/2/3/4-
Y1/2/3/4+
PLC
+
–
COM
IN
SSDC
5 - 24V
Power Supply
Y1/2/3/4-
Y1/2/3/4+
CLP
+ –
IN
COM
SSDC
5 - 24V
Power Supply
+ –
Y1/2/3/4-
Y1/2/3/4+
SSDC
5 - 24V
Power Supply
Load
Y1/2/3/4-
Y1/2/3/4+
+ –
relay
SSDC
5 - 24V
Power Supply
1N4935 suppression diode
