7.3 Mating Connector to the Drive
v Description P/N Vender
J1 Power Connector Housing：39-01-3028 Crimp：39-00-0038 Molex
J2 Motor Connector Housing：39-01-3048 Crimp：39-00-0038 Molex
J3 Encoder Connector Housing：501646-1600 Crimp：501648-1000 Molex
J4 I/O Connector Housing：501646-3200 Crimp：501648-1000 Molex
