www.miinet.com Moore Industries-International, Inc.
- 128 -
User’s Manual
238-741-00K
May 2019
Unit
Input Output
Power Options
Housing
TDZ
3
Smart
HART
Temperature
Transmitter
with Display
PRG
Programmable with
standard HART
communicator or
HART compatible host;
program or monitor
with any FDT compliant
host or program, such
as PACTware, utilizing
our DTM.
RTD
2-, 3-, 4-Wire
Platinum,
Copper, Nickel
Thermocouple
(J, K, E, T, R, S, B,
N, C)
0-4000 ohms
-50-1000mV
(see Table 1
in Section 7 for
additional information)
4-20MA
Scalable
to narrower
ranges
12-42DC*
12-30DC
Intrinsically
Safe (I.S.)
applications.
* Non-incendive
(Class 1 Div
2, Zone 2) by
default
None HP Hockey puck housing and spring clips
DN Snap-in mounting for HP case on TS-
32 DIN-rail
FL Mounting anges on HP for relay track
or screw mounting
FLD Mounting anges on HP for 3½” relay
track mounting
BH2NG (*) or (‡) Explosion-Proof
enclosure with two 1/2-inch NPT entry
ports and a glass cover
BH2TG (*) or (‡) Explosion-Proof
enclosure with two 3/4-inch NPT entry
ports and a glass cover
BH2MG (*) or (‡) Explosion-Proof
enclosure with two M20 x 1.5 NPT entry
ports and a glass cover
BH3NG (*) or (‡) Explosion-Proof
enclosure with three 1/2-inch NPT
entry ports
BH3TG (*) or (‡) Explosion-Proof
enclosure with two 3/4-inch side-entry NPT
ports, one 1/2” bottom port, and a
glass cover
BH3MG (*) or (‡) Explosion-Proof
enclosure with two, M20 x 1.5 side-entry
ports, one 1/2” bottom-entry port, and a
glass cover
SB2NG (*) or (‡) 2-Hub, Explosion-Proof
enclosure with two, ½-inch NPT entry ports
and a glass cover
SB2MG (*) or (‡) 2-Hub, Explosion-Proof
enclosure with two, M20 x 1.5 entry ports
and a glass cover
D2LC 2-Hub, low base, clear cover, IP66/
NEMA 4X enclosure
* Either A or E su󰀩x (comes supplied with 2” pipe mount
hardware)
A su󰀩x indicates ANZEx/TestSafe (Ex d) Flame-
Proof approvals (i.e. BH2MGA)
E su󰀩x indicates ATEX (Ex d and tD) Flame-Proof
approvals (i.e. BH2MGE)
‡ P su󰀩x indicates enclosure comes equipped with base
plate and U-bolts for mounting on a 2-inch pipe
(i.e. BH2NGP)
Additional Parts
The communications cables must be
purchased separately:
P/N 804-030-26–Non-Isolated Fuse Protected
USB Communication Cable (required by IECEx
and ATEX for products installed in Intrinsically
Safe areas)
P/N 803-040-26–Non-Isolated Serial Configuration
Cable for 2-Wire Instruments
P/N 804-021-26–HART-to-USB Smart Interface
Cable with HART Modem.
To order, specify: Unit / Input / Output / Power / [Housing]
Model Number Example: TDZ
3
/ PRG / 4-20MA / 12-42DC / [BH2NGP]
Field Mount Unit with Display
Programmable Smart HART Temperature Transmitter
THZ
3
/ TDZ
3
SECTION 9
