SECTION 4
DD Device Setup Reference Guide
The following provides a comprehensive list of conguration menus and options which can
be used as a quick reference guide to identify the di󰀨erent conguration capabilities and
locate them in the menu system. For more information on the specic features please refer
to the Conguration Overview and the specic menu descriptions.
Note: * Is used to identify advanced features which are only accessible by enabling Advanced
Settings in the SETUP menu.
Process Variables
This menu is for information only. It displays PV parameters and values and allows selection
of all Dynamic and Device Variables to display their present values and quality.
Setup
Default Config- Reset to factory default (see Quick Start Guide for default configuration settings)
Config Wizards- Configuration Wizards to simplify programming:
Basic Wizard – Configures a single sensor or dual identical sensors
Drift Wizard – Set up a Drift Alert between two sensors (see Section 1 Sensor
Diagnostics)
Input
Filter – 50Hz or 60Hz input filter to reduce mains induced noise
PV Damping – introduces a delay in the response to stop input noise from generating
output errors
Configure Sensor:
Input Type (eg. Thermocouple TypeK, 4W RTD Pt3850 100ohm etc.)
RJC Temp EGU
Sensor 1 /2 EGU (engineering units)
Sensor 1 /2 Broken Wire detection & hold off
Sensor 1/2 Running Average filter
Sensor 1/2 2 wire offset (2W RTD/resistance only)
Sensor 1/2 Information (Limits, span, serial number)
Sensor 1/2 Scaling
*Sensor 1/2 Custom Curve
Ranging & Mapping
Variable Mapping- assigns the Device Variables (eg. SEN1, BU1-2) to the
HART Variables (PV, SV etc.)
Smart Range –sets the PV lower range and upper range values to AO 0-100%
