Moore Industries THZ3 - Dimensions

www.miinet.comMoore Industries-International, Inc.
- 29 -
User’s Manual
238-741-00K
May 2019
Programmable Smart HART Temperature Transmitter
THZ
3
/ TDZ
3
Dimensions
Figure 3.2. Dimensions of Aluminum DIN Housing
Figure 3.3. Dimensions of Aluminum HP Display Housing
ADDR
ADD
ADD
R
R
62mm
(2.45 in)
75mm
(2.97 in)
75mm
(2.50 in)
TDZ
3
Figure 3.4. Dimensions of THZ
3
HPP Housing
32mm
1.27in
48mm
1.90in
51mm
2.04in
33mm
1.30in
SECTION 3
5.31 in
[135mm]
4.04 in
[102.6mm]
1.11 in
[28mm]
SMART HART
TEMPERATURE
TRANSMITTER
DUAL SENSOR
