Moore Industries THZ3 - Table of Contents

www.miinet.com Moore Industries-International, Inc.
- 4 -
User’s Manual
238-741-00K
May 2019
Table of Contents
Programmable Smart HART Temperature Transmitter
THZ
3
/ TDZ
3
SECTION 5
THZ3/TDZ3 Quick Start Guide ...........................................................5
Section 1 - Introduction 6
Overview....................................................................................................................6
Model Numbers and Options
...................................................................................7
Measurement Modes and Device Variables
...........................................................9
Sensor Diagnostics
................................................................................................11
Section 2 - Calibration and Bench Check 14
Bench Check ...........................................................................................................26
Section 3 - Installation and Wiring 28
Terminal Designations ...........................................................................................28
Dimensions
.............................................................................................................29
Installation in Hazardous Locations
..................................................................... 36
Specic Conditions of Use
.................................................................................... 37
Section 4 - Conguration 43
Programming Device Description Menu on THZ
3
/TDZ
3
with HART Communicator
handheld devices ...................................................................................................50
DD Device Setup Reference Guide
.......................................................................55
Section 5 - Conguration using FDT/DTM Software 75
THZ
3
/TDZ
3
DTM Parameter in Basic Setup Conguration .................................91
THZ
3
/TDZ
3
DTM Parameter Advanced Setup Conguration ...........................104
Section 6 - Operation and Maintenance 113
Section 7 - Applications 121
Section 8 - Specications 124
Section 9- Ordering Information 127
Section 10 - Certication Information 129
Warranty Disclaimer 140
