Figure 3.5. Dimensions of BH2 Housing
+PS
-PS1 2
34
68mm
(2.68 in)
GND
1/2 NPT
102mm
(4.02 in)
84mm
(3.31 in)
68mm
(2.68 in)
127.7mm
(5.03 in)
10mm
(0.38 in)
124mm
(4.88 in)
25mm
(1.00 in)
102mm
(4.02 in)
119mm
(4.69 in)
76mm
(2.99 in)
57mm
(2.24 in)
22mm
(0.87 in)
SIDE VIEW
TOP VIEW
ADDR
ADDR
ADDR
ADDR
TDZ
3
Programmable Smart HART Temperature Transmitter
THZ
3
/ TDZ
3
SECTION 3
