Figure 3.6. Dimensions of BH3 Housing
89mm
(3.50 in)
124mm
(4.90in)
70mm
(2.75 in)
57mm
(2.25 in)
31mm
(1.25 in)
62mm
(2.45 in)
89mm
(3.50 in)
44mm
(1.75 in)
25.4mm
(1.0 in)
32mm
(1.25 in)
6.6mm
(.26 in)
70mm
(2.75 in)
57mm
(2.25 in)
76mm
(2.99 in)
TOP VIEW
BACK VIEW
SIDE VIEW
65mm
(2.56 in)
GND
101mm
(4.0 in)
115mm
(4.55in)
ADDR
ADDR
ADDR
