Figure 3.7. Dimensions of LH Housing
93mm
(3.68 in)
9mm
(0.35 in)
87mm
(3.43 in)
Conduit
Entry Port
89mm
(3.5 in)
84mm
(3.31 in)
C
L
61mm
(2.40 in)
2-in Pipe Bracket
Mounting Holes (4)
61mm
(2.40 in)
Process Connection
1/2-in NPT (N and M models) or
G½ (BSP) (C models)
61mm
(2.40 in)
10-32
Mounting
Holes (2)
51mm
(2.01 in)
Safety Lock
(LH2 only)
Metal Tag
BOTTOM
INSIDE
2-INCH PIPE MOUNTING HARDWARE
30mm
(1.18 in)
DIA. 72mm
(DIA. 2.83 in)
Instrument
Mounting Holes
40mm (1.56 in)
Instrument
Mounting
Holes
33mm
(1.30 in)
I.D. 62mm x 19mm Deep
(2.44 in x 0.75 in Deep)
Ground
M4.0 x 0.7
(4 places)
FRONT
SIDE*
*LH1 Connection
Head Shown
