Moore Industries THZ3 - Page 33

www.miinet.comMoore Industries-International, Inc.
- 33 -
User’s Manual
238-741-00K
May 2019
Programmable Smart HART Temperature Transmitter
THZ
3
/ TDZ
3
Figure 3.8. Dimensions of D-Box Housing
ADDR
TDZ
3
84mm
(3.31 in)
118mm
(4.65 in)
130mm
(5.12 in)
112mm
(4.41 in)
83mm
(3.27 in)
64mm
(2.52 in)
Interior Diameter
81mm (3.2 in)
Instrument
Tag
116mm
(4.57 in)
27mm
(1.06 in)
Conduit
Fitting
Cover
Body
Bezel
ADDR
ADDR
TDZ
3
Z
Z
SECTION 3
