SECTION 1
OPTIONS
-RF
Applies to DIN housing only. This option provides enhanced RFI/ EMI filtering with protection of
20 V/m @ 80-1000 MHz, 1kHz AM.
-AIS
Applies to DIN housing only. Allows direct connection of sensors from an intrinsically safe area by
providing a built in intrinsically safe barrier. Units with this option have blue input terminals.
HOUSING
[HP]
The TDZ
3
with display is available in an HP housing. The THZ
3
is not available in this housing.
The HP unit can also be ordered in an explosion proof or protective enclosure eg. BH, SB, D-Box
etc. or with a clip for DIN rail or track mounting.
[HPP]
The THZ
3
is available in an HPP housing. The TDZ
3
is not available in this housing.
Encapsulated hockey-puck housing for mounting in connection heads. The HPP unit can also be
ordered in an explosion proof or protective enclosure eg. LH1, LH2.
[DIN]
The THZ3 is available in a DIN housing. The TDZ3 is not available in this housing.
DIN-style aluminum housing mounts on 35mm Top Hat DIN rail (EN50022).
Please refer to Section 9 Ordering Information for all housing options.
