Pre Start Inspection and Operation
3.5
NOTE:Some items in Figure 3–5 have been removed for clarity.
6. Check all hydraulic hoses, lines, and ttings.
Hydraulic oil under pressure can penetrate body tissue causing serious injury and
possible death. When troubleshooting a hydraulic system for leaks, always use
cardboard or wood as a detector. DO NOT USE YOUR BARE HANDS. If you are
injected with hydraulic oil or any other uids, immediately seek treatment by a doctor
trained in the treatment of penetrating uid injuries.
Figure 3-5 Radiator Air Flow Inspection
