Auxiliary Hydraulic Screw Pump
The Morehouse Auxiliary Hydraulic Screw Pump is a manual hydraulic pump that is specically designed to ad-
just and maintain the calibraon force in a UCM at a ne level. This gives the operator beer control over the
calibraon force and enables accurate calibraon at any desired force.
For UCMs with the Universal Hydraulic Pump, it is mounted on the body of the Universal Hydraulic Pump unit
for easier handling. For UCMs with the hydraulic hand pump, it is an opon that can be installed directly on the
UCM frame.
Figure 7: Auxiliary Hydraulic Screw Pump Mounted on:
a) UCM Frame; b) Universal Hydraulic Pump
(a)
(b)
For more details see the Auxiliary Hydraulic Screw Pump Instrucon Manual PM-5252.
