Figure 20: Tension Members with Adapters for UCMs 100,000 lbf (500 kN)
Capacity and Less
Adapter is threaded on one
side to match the coupling
nut on the tension member
Adapter is threaded on the
other side to adapt to various
instrument sizes
Unit under test
Rust-resistant black oxide coang on
all adapters
Simplify setups by using one tension
member with several adapters
For more details see the Universal Calibrang Machine Adapters and Accessories PG-5202.
