Figure 21: Morehouse Quick Change Tension Members
Quick Change Tension Member
A single Tension Member Assembly is installed into the
UCM and mulple tension adapters, both male and fe-
male, are interchanged to aach the desired-size instru-
ment.
A single pair of Tension Members can re-
main xed in the machine and by swapping
out both male and female tension adapt-
ers, three dierent load cell sizes can be
calibrated in the UCM by user.
One end of the tension adapter always
has the same size thread on it so that any
adapter chosen will t the master-size Ten-
sion Member Assembly.
For more details see the Universal Calibrang Machine Adapters and Accessories PG-5202.
