Indicated Items on the Rating Label and X-ray Tube Head Assembly Label
* For details, refer to ā
Technical Specifications
ā (p. 92).
* Some symbols described on the previous page may be included.
Model: Model of X-ray system
Type: Type
Input: Rated input voltage, frequency, and power in operation
Standby: Input power in standby
Duty Cycle: Duty cycle of X-ray system
2D barcode at bottom right: Label code
MODEL: Model of tube housing assembly
HEAD NO.: Serial number of tube housing assembly
D AT E O F M F G. : Date of manufacture
TOTAL FILTRATION: Min. inherent filtration
RATING: Rated output of tube housing assembly
TUBE MODEL: Model of X-ray tube
TUBE ANODE NO.: Serial number of X-ray tube
MFD. BY: Manufacturer of X-ray tube
EFFECTIVE FOCAL SPOT: Nominal focal spot value
X-ray Tube Head Assembly Label
