6. Beam On/Off Keys
Positioning beams automatically go off after 3 minutes. Press either one of these keys to turn them back on. Or
press one of them to turn the beams off.
7. Incisal Occlusion Key
This key is used to make a panorama exposure for a patient with standard occlusion biting on a mouthpiece. After
adjusting the height of the positioning (AF) sensor, press this key to automatically move the arm backwards or
forwards to the optimum position.
8. Natural Occlusion Key
This key is used to make a panorama exposure for a patient with standard occlusion without using a mouthpiece.
After adjusting the height of the positioning (AF) sensor, press this key to automatically move the arm backwards
or forwards to the optimum position.
9. Protruding Maxillary Occlusion Key
This key is used to make a panorama exposure for a patient with protruding maxillary without using a mouthpiece.
After adjusting the height of the positioning (AF) sensor, press this key to automatically move the arm to the
optimum position.
10. Protruding Mandibular Occlusion Key
This key is used to make a panorama exposure for a patient with protruding mandible without using a mouthpiece.
After adjusting the height of the positioning (AF) sensor, press this key to automatically move the arm to the
optimum position.
11. Frame Liquid Crystal Display (LCD)
Display various information including Ready mode, Image layer beam position, exposure mode, exposure
conditions, patient positioning guide etc.
12. Frankfort Plane Beam Up/Down Knob
Turn the knob to the right to lower the beam or to the left to raise the beam. For panorama exposures, lines up
with the patient’s Frankfort plane.
13. Auto Positioning (AF) Sensor Beam Up/Down Knob
Turn the knob to the right to lower the beam or to the left to raise the beam. Adjust the beam so it strikes the
center of the mouthpiece in the patient’s mouth.
