Morita veraviewepocs 2d User Manual

95
Power Requirements
EX-1
EX-2
Input Voltage
AC120 V
AC 220/230/240 V
60 Hz single phase
50-60 Hz single phase
Line Voltage regulation
*1
Max. 8 %
Max. 8 %
Range of line voltage
108 to 132 V
(Including Line voltage
regulation)
AC 220/230/240 V ± 10 %
(Including Line voltage
regulation)
Line current
(Operation)
Panoramic, Upgradable Cephalometric:
Max. 19 A
10.4/ 10/ 9.5 A
With Cephalometric:
Max. 21.3 A
10.4/ 10/ 9.5 A
(Stand by)
Max. 1.2 A
1.0 A
Technique factor for the Maximum line current
Panoramic, Upgradable Cephalometric:
80 kV, 10 mA
80 kV, 10 mA
With Cephalometric:
90 kV, 10 mA
90 kV, 10 mA
Power Consumption
Panoramic, Upgradable Cephalometric:
Max. 2.0 kVA
2.3 kVA
With Cephalometric:
Stand by
Max. 2.3 kVA
0.3 kVA
2.3 kVA
0.3 kVA
Fuse at the distribution panel
20 A, 120 V, slow
*The maximum current rating of
this X-ray unit is momentary.
The recommended ampacity of
supply circuit conductor and the
current rating of over current
protection device are based on the
National Electrical Code 2017,
Article 517, Part V, X-ray
Installation
16 A, 220/230/240 V, slow
Power line resistance
Max. 0.5 Ohm
Max. 1 Ohm
Means isolation from supply mains EX-1: Mains plug, EX-2: Main switch
Circuit breaker shall be applied on distribution panel. It is recommended to wire a breaker only for this unit.
*1
Line-voltage regulation = 100 (Vn – Vi) / Vi
Vn = No-load line voltage, Vi = Load line voltage
Mechanical Parameters
Panoramic SID 518.5 mm (± 20 mm)
Cephalometric SID 1,650 mm (± 20 mm)
Magnification Standard Panoramic: 1.3×, 1.6×
Maxillary Sinus Panoramic: 1.5×
Pedodontic Panoramic: 1.3×, 1.6×
Shadow Reduction Panoramic: 1.3×, 1.6×
Orthoradial Panoramic: 1.3×, 1.6×
TMJ Quadruple: 1.3×,
Cephalometric: 1.1×
X-ray Field Panoramic: W6 × H143 mm
(W: +1mm or less on each side, H: inside image reception area)
Cephalometric: W6 × H220 mm
(W: +1mm or less on each side, H: inside image reception area)
Weight Panoramic: Approximately 184 kg Boxed
Cephalometric: Approximately 268 kg Boxed
Outer Dimensions
Main Unit W 1,020 × D 1,330 × H 2,355 mm (H 2,185 mm Option)
(Panoramic, Upgradable Cephalometric)
W 2,000 × D 1,330 × H 2,355 mm (H 2,185 mm Option) (with Cephalometric)
Control box W 70 × D 40 × H 115 mm
