Instruction Manual
MORSØ Mitring Machine
Model F
10
Description of the Lever System
The cutting movement is achieved manually.
The vertical length of the stroke of the knives is adjusted at the factory to 165 mm, but this
can be re-adjusted to max. 200 mm, if necessary, (see chapter F-6).
The cutting action is achieved by a foot operated lever mechanism.
The pedal (34) is pressed down.
The foot pedal tipper (35) pulls the draw bow (38), draw bar (40), and the knife block (4)
down.
Double return springs (42) ensure the pedal (34) and knife block (4) are returned to the start
position when the foot pressure is relieved from the foot pedal.
There is an adjustable pedal height stop facility (41), which can also be used as a safety
feature to lock the knife block and knives in the down position.
Functional Description B-4
