Instruction Manual
MORSØ Mitring Machine
Model F
13
Technical Data
Technical Data
Machine Dimensions (max.): Working Capacity:
Length (a) 2.200 mm Double Mitre 45°
Width (b) 510 mm
Single Mitre (left-right) up to 90°
Height (c) 1150 mm Length of Moulding from 100 mm
to max 1,500 mm
Weight 90 kg
Siting Considerations Working Width (max.) * 100 mm
Distance to Wall min.1000 mm Working Height (max.)* 145 mm
Noise/Pollution: Square Cutting (max.) 65/65 mm
Noise Level silent Measuring Scale (up to) 1,500 mm
Pollution nil/no dust
*see diagram, page C-2 and service F-6
Technical Data C-1
