Instruction Manual
MORSØ Mitring Machine
Model F
18
Operating Devices
19 = Handle - secures the left hand fence 24 = Star Wheel – tightens, to secure the
measurements stop.
21 = Scale – in degrees
for adjustment of left hand fence 26 = Scale (Rule) – in inches or mm,
facilitates measurement of
work piece to be cut.
20 = Handle - secures the right hand fence
22 = Scale – in degrees
for adjustment of right hand fence 34 = Foot pedal - cutting function of the
knife block when pressed down.
31 = Rebate Support
33 = Knurled Nut - height adjustment of
rebate supports
41 = Travel lock bolt – adjustment lock
determines the height stop for the
pedal/knife block. (Can also be used
to lock the pedal/knife block in the
down position as a safety feature at
cessation of work).
13 = (Hand) Lever - movement from
left to right - moves knife block
forward or back. (Should ALWAYS
be pressed down during movement
to stop the tooth wearing in the tooth
arc as it travels over the notches.)
48 = Star wheel – secures the safety guard
in place
16 = Tooth Arc – regulates the left and right
movement of the lever (13).
Remember, the last tooth spacing is
half that of the other teeth, because it
is the ’trim cut’.
.
Operating Instructions E-1
