Working Procedure
The right hand side of the moulding is trimmed to 45°.
Place the knife unit (a) must in the rearmost position and the knife block (4) in the topmost
position.
Place the moulding on the machine table (2) and push it up to the adjusted stop beam (25)
(see E-4).
Working with mouldings with a rebate the rebate supports (31) are adjusted as described
under E-5.
With the lever (13) the knife unit (a) is moved to a suitable starting position on the moulding.
E.g. working with a 60 mm wide moulding the knife unit (a) is moved about 40 mm forward.
The foot pedal (34) is pressed home, then the foot pressure is relieved so that the springs
can return the knife block (4) back to start position.
The lever (13) is moved a couple of notches further to the right in the tooth arc (16) and the
next cut is made.
Proceed in this manner until the moulding is cut through.
The last cut must always be a small cut (trim-cut). Even with small mouldings that could
easily be cut in one cut you must make the last small cut in order to achieve a good result.
The tooth arc (16) is constructed so that the last tooth only has half the travel compared to
the other teeth.
After Working Procedure
Clean the machine.
Remove the waste.
Check the whole machine.
The knife block should be locked in the bottom position using the height stop, as a safety
precaution (41).
