Instruction Manual
MORSØ Mitring Machine
Model F
44
Adjustment of Height Movement
The height movement of the knife block (4) is adjusted to 145 mm at the factory.
In the following manner the machine can be adjusted to a height movement of max. 185 mm:
1. The knife block unit (4) is placed in the rearmost position.
2. A piece of wood is put on the table (2) under the knives in order to prevent the knife block
(4) falling down during the adjustment.
3. The springs (42) are removed from the spring anchors (43) and draw bow holders (39).
4. The draw bow holders (39) which are located in the rearmost holes in the foot pedal tipper
(35) are relocated to the foremost holes in the foot pedal tipper (35).
5. Fasten the draw bow holders (39) in the draw bow (38) again.
6. Place the springs (42) in the spring anchors (43) and the draw bow holders (39).
7. The draw bar (40) is adjusted as described under F-4.
Service F-6
