Instruction Manual
MORSØ Mitring Machine
Model F
8
Machine Description
The MORSØ-F is constructed as a compact machine with a sturdy frame (1) and built in lever
system (46) (not shown).
The cutting assembly is situated on top of the machine.
The knife block (4) slides up and down in the slide frame (10) fitted at the cross (11), and
forwards and rearwards in the guides (12) and a cross guide in the table (2).
The razor sharp knives (5) bolted onto the knife block (4) effectively cut the mouldings.
The forward and rearward movement of the knife block assembly is operated manually by the
lever (13) at the front of the table (2).
The vertical movement of the knife block is achieved by pressing the foot pedal (34)
downwards. The built in lever system makes this operation effortless. Double heavy duty
return springs (42) (not shown) return the knife block to the start position.
The moulding is placed on the table (2) against the fences (17) + (18) which has been
adjusted to the required angle (usually 45 degrees), and the rebate supports (31) are
adjusted to the height and depth of the moulding rebate.
The required length of the moulding is selected by movement of the moulding stop block (23)
and the stop beam (25). Measurement of the work piece length can be read off the
measurement facility (26) located on the table extension (3).
Functional Description B-3
