MOTO GUZZI GRISO User Manual

FUEL SYSTEM
3 - 8
Griso V1100
• Loosen and remove the two screws.
• Disconnect the vacuum tube.
• Disconnect the blow-by reservoir breather hose.
• Remove the hose ties.
• Remove the tie from water breather hose on air box
right side and remove the hose.
• Working on either side, loosen and remove the tie.
• Remove the air box from behind, collect the blow-by
drain hose.
www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten

MOTO GUZZI GRISO Specifications

General

Cooling System	Air-cooled
Final Drive	Shaft drive
Seat Height	800 mm
Engine Type	90° V-twin
Fuel System	Electronic fuel injection
Front Suspension	43mm upside-down fork
Front Brakes	Dual 320mm discs, 4-piston calipers
Frame	Tubular steel
