MOTO GUZZI GRISO User Manual

CHASSIS
6 - 4
Griso V1100
6.1.2 REMOVING THE FORK LEGS
• Working on either side, loosen and remove the two
front brake calliper screws and remove the calliper
from its housing.
• Support the front end of the vehicle.
• Loosen and remove the wheel shaft fixing nut and set
aside the washer.
• Working on either side, loosen the screws of the wheel
shaft clamps.
• Lightly tap the wheel shaft with a rubber mallet until the
holes on the opposite side are uncovered.
www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten

MOTO GUZZI GRISO Specifications

General

Cooling System	Air-cooled
Final Drive	Shaft drive
Seat Height	800 mm
Engine Type	90° V-twin
Fuel System	Electronic fuel injection
Front Suspension	43mm upside-down fork
Front Brakes	Dual 320mm discs, 4-piston calipers
Frame	Tubular steel
