MOTO GUZZI GRISO User Manual

GENERAL TECHNICAL INFORMATION
2 - 24
Griso V1100
2.2.5 ADJUSTING VALVE CLEARANCE
When the timing system is noisy, check the clearance
between valves and rocker arms.
NOTE Adjust clearance when the engine is cold, with the
piston at top dead centre (TDC) during the compression
stroke (valves closed).
• Loosen and remove the three screws and remove the
side protection.
• Working on either side, loosen and remove the two
outer screws and remove the spark plug protection.
• Working on either side, loosen and remove the two
inner screws and remove the insert.
• Disconnect both spark plug caps.
www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten

MOTO GUZZI GRISO Specifications

General

Cooling System	Air-cooled
Final Drive	Shaft drive
Seat Height	800 mm
Engine Type	90° V-twin
Fuel System	Electronic fuel injection
Front Suspension	43mm upside-down fork
Front Brakes	Dual 320mm discs, 4-piston calipers
Frame	Tubular steel
