43
Product Number 011-1870-6
AC POWER
AC output voltage (nominal) 115 V, 60 Hz
Maximum AC output power 300 W
Continuous power 240 W
Maximum AC output surge power 480 W
AC output frequency 60 ± 1 Hz
AC output waveform Modied sine wave
DC POWER
USB output 5 V / 2.1 A
No load current draw (at 12 V) < 0.3 A
Eciency (maximum) 85%
Low-voltage shutdown 10.0–11.0 V
High-voltage shutdown 15.0–16.3 V
PHYSICAL SPECIFICATIONS
Ambient operating temperature range 0 to 40 °C (32 to 104 °F)
Dimensions (L x W x H) 7/ x 3/ x 2” (187 x 100 x 50 mm)
Weight 1 lb 3 oz (550 g)
This manual contains information that relates to PROTECTING PERSONAL
SAFETY and PREVENTING EQUIPMENT PROBLEMS. It is very important to read
this manual carefully and understand it thoroughly before using the product.
The symbols listed below are used to indicate this information.
DANGER!
Potential hazard that will result in serious injury or loss of life.
WARNING!
Potential hazard that could result in serious injury or loss of life.
CAUTION!
Potential hazard that may result in moderate injury or damage to equipment.
IMPORTANT!
Installation, operation, or maintenance information that is important but not hazard
related.
TECHNICAL SPECIFICATIONS
SAFETY INFORMATION
011-1870-6-Mobile-Power-Outlet_300W-EN-07.indd 3-4 12/13/12 7:22 PM
