03. CONFIGURATION 03. CONFIGURATION
EXTENDED MENU 1 EXTENDED MENU 1
The control board is supplied by the manufacturer with the deactivated photocells test.
Activate (LED ON)/deactivate (LED OFF) function:
01. Activate the extended menu 1
02. Press SEL button once and the LED AUT/P-P will begin to flash.
03. Press SET button for 1 second
04. The LED CODE ON indicates that the function is disabled and the LED off indicates
that the function is activated.
NOTE • If you do not have the photocells installed, this test will not work.
• CODE | TEST OF PHOTOCELLS
The pressure function of the motors, makes that with control board send the order of 2
seconds of closing, once every two hours.
The control board is supplied by the manufacturer with functionality to keep pressure
OFF the hydraulic motors.
Activate (LED ON)/deactivate (LED OFF) function:
01. Activate the extended menu 1.
02. Press SEL button as often as necessary until the LED CODE PED will flashing
• CODE PED | MOTORS PRESSURE
With the blocking function activated whenever the photocells (DS2) detected an obsta-
cle, the gate movement will stop and only again be triggered when you press the remote
control button. Before the gate resume movements, the flash lamp will flash during 5
seconds.
The control board is supplied by the manufacturer with blocking disabled.
With the closing push function, the control board case is programmed with decele-
ration, will add 1 second acting at full motor power, so that the gate can overcome
the lock.
The control board is supplied by the manufacturer with the closing push disabled.
Activate (LED ON)/deactivate (LED OFF) function:
01. Activate the extended menu 1.
02. Press SEL button as often as necessary until the LED T. MOT. will flashing
03. Press SET button for 1 second
04. The LED T.MOT. on indicates that the function is activated and the LED off indi-
cates that the function is disabled.
• T. MOT. | CLOSING PUSH
• T. MOT. PED | SAFETY DEVICE 2 / BLOCKING
The function opening push, facilitates the release of the lock when the opening is ac-
tuated, ensuring proper operation.
The control board is supplied by the manufacturer with the opening push disabled.
Activate (LED ON)/deactivate (LED OFF) function:
01. Activate the extended menu 1.
02. Press SEL button as often as necessary until the LED INB. CMD. AP. will flashing
03. Press SET button for 1 second
04. The LED INB. CMD. AP on indicates that the function is activated and the LED off
indicates that the function is disabled.
• INB. CMD. AP. | OPENING PUSH OF
03. Press SET button for 1 second
04. The LED CODE PED on indicates that the function is activated and the LED off indi-
cates that the function is disabled.
The function of programming the remote controls on distance, it allows them to be ad-
ded remote controls to the new control board without having to use the SEL button. The
control board is supplied by the manufacturer with programming remote controls on
distance deactivated.
Activate (LED ON) / deactivate (LED OFF) function:
01. Activate the extended menu 1.
02. Press SEL button once and the LED AUT/P-P will begin to flash.
03. Press for 1 second the SET button.
04. LED AUT/P-P ON indicates that the function is active and the LED off indicates that
the function is disabled.
Programming of remote controls on distance:
01. Press for 10 seconds the button of the remote control a previously memorized.
02. LED CODE will flash.
03. Press for 1 second one button of the remote control that you want to program.
04. The flash lamp will flash confirming the success of the operation.
• AUT/P-P | PROGRAMMING OF THE REMOTE CONTROL ON DISTANCE
