Motorline OL2000 - Technical Specifications; Description of the System

Fig. 04
1. Motor
2. Control board
3. Receiver
4. Left limit switch plate
5. Right limit switch plate
6. Rack
7. Key selector
8. Photocell column
9. Safety photocells
10. Antenna
11. Warning light
12. Safety edge
Technical specications of the automated operator:
Model
Power supply (V)
Rated absorbed power (W)
Max speed (m/sec)
Working time
Noise
Operating temperature (ºC)
Protection class
Thermal protection (ºC)
Leaf max weight (Kg)
Working frequency
Capacitor
3) TECHNICAL SPECIFICATIONS
4) DESCRIPTION OF THE SYSTEM
Pág. 03
8
4
1
6
5
8
9
7
11
12
9
2
3
10
800A
230V , 50Hz
370W
12m/min
15min
≤ 56dB
>-35ºC , <65ºC
IP44
120ºC
800Kg
40%
12uF
OL1500
230V , 50Hz
550W
12m/min
240min
≤ 56dB
>-45ºC , <65ºC
IP44
120ºC
1500Kg
70%
16uF
OL2000
230V , 50Hz
1000W
12m/min
240min
≤ 56dB
>-45ºC , <65ºC
IP44
120ºC
2000Kg
70%
16uF
