Number Description
5 Navigation Button
Use these buttons for list scrolling and navigating around the menu hierarchy.
6
*
Accessory 2-Dot Button
Use this programmable button to access a preprogrammed function or enable or
disable a feature.
7
*
Accessory 1-Dot Button
Use this programmable button to access a preprogrammed function or enable or
disable a feature.
8
*
Accessory No-Dot Button (Purple)
Use this programmable button to access a preprogrammed function or enable or
disable a feature.
9 Push-to-Talk (PTT) Button
Press and hold to talk in simplex calls or to initiate a group call, release it to listen.
10
*
Orange Button
This button is usually programmed as the Emergency button.
11 Mode Knob
Rotate this knob to scroll through the channel list.
12 Screen Display
13 Power On/Off Button
Press and hold to turn on/off your radio.
14 Home Button
Press to return to the Home screen.
15 Dimmer Button
Press to adjust the display brightness.
Press and hold to toggle between day and night mode.
16 Volume Knob
Rotate clockwise to increase the volume.
Rotate counterclockwise to decrease the volume.
17
*
Data Feature Button
Press to enter the Text Messaging Service feature screen.
Press and hold to enter the Inbox menu.
18 Home Button (Microphone)
Press to return to the Home screen.
19 Keypad Buttons
Use the keypad to enter alphanumeric characters for dialing, contact entries, and
text messages.
20 Okay/Select Button
Press to select the option that appears on the screen.
21 Cancel Button
Press to cancel the current operation and return to the previous screen.
6875947M01-HM
Radio Controls
18

Motorola APX Series Specifications

General

Operating Temperature	-30°C to +60°C
Bluetooth	Yes (Optional)
GPS	Yes (Optional)
Frequency Range	VHF, UHF, 700/800 MHz
Dimensions	Varies by model
Weight	Varies by model
Encryption	AES, DES
IP Rating	IP67
Digital Technology	P25 Phase 1 and Phase 2
Display	Full-color, high-resolution display
