Motorola ASTRO Digital Spectra Service Manual

7-24 Schematics, Component Location Diagrams and Parts Lists: Command Board Section
October 28, 2002 6881076C25-D
C581 2113740B65 CAP CHIP REEL CL1 +/-30
470
C582 2113740B65 CAP CHIP REEL CL1 +/-30
470
C583 2113740B65 CAP CHIP REEL CL1 +/-30
470
C584 - - - - - - - - - NOTPLACED
C585 2113740B65 CAP CHIP REEL CL1 +/-30
470
C586 thru
C589
2113743G24 CAP CHIP 2.2 UF 16V +80-
20%
C591 2113740B36 CAP CHIP REEL CL1 +/-30
30
C592 2113740B65 CAP CHIP REEL CL1 +/-30
470
C601 2311049J26 CAP TANT CHIP 10 20 16
2, 3, 4, and 5
C602 2113740B65 CAP CHIP REEL CL1 +/-30
470
C604 2113741N69 CAP CHIP CL2 X7R 10%
100000
C605 2311049J26 CAP TANT CHIP 10 20 16
2, 3, 4, and 5
C801 2113741N69 CAP CHIP CL2 X7R 10%
100000
C802 thru
C804
2113740B65 CAP CHIP REEL CL1 +/-30
470
C805 2113741N69 CAP CHIP CL2 X7R 10%
100000
C806 2113740B65 CAP CHIP REEL CL1 +/-30
470
C807 2113741N69 CAP CHIP CL2 X7R 10%
100000
C808, C809
& C811
2113740B65 CAP CHIP REEL CL1 +/-30
470
C813 2113741N69 CAP CHIP CL2 X7R 10%
100000
C814 2113740B65 CAP CHIP REEL CL1 +/-30
470
C815 2113741N69 CAP CHIP CL2 X7R 10%
100000
C816 & C817 2113740B65 CAP CHIP REEL CL1 +/-30
470
C818 2113741N69 CAP CHIP CL2 X7R 10%
100000
C819 2113743G21 CER CHIP CAP 1.0 UF
C820 thru
C822
2113740B65 CAP CHIP REEL CL1 +/-30
470
C860 thru
C877
2113740B65 CAP CHIP REEL CL1 +/-30
470
CR400 4813833C10 DIODE GEN PUR 70V
MMBD6050
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
CR401 4813833C03 DIODE DUAL 70V ’A1X’
BAW56LT1
CR402 - - - - - - - - - NOTPLACED
CR403,
CR500 &
CR501
4813833C10 DIODE GEN PUR 70V
MMBD6050
CR502 - - - - - - - - - NOTPLACED
CR503 4813833C10 DIODE GEN PUR 70V
MMBD6050
CR504 - - - - - - - - - NOTPLACED
CR600 4813833C10 DIODE GEN PUR 70V
MMBD6050
F500 6505663R06 FUSE 7 AMP
F501 6505663R03 FUSE 5 AMP
J500 0980104M02 RECEPTACLE BOTTOM
ENTRY
JU500 - - - - - - - - -
0611077A01
NOTPLACED
1, 2, and 3
RES CHIP JUMPER
4 and 5
JU501 - - - - - - - - - NOTPLACED
JU502 0611077A01 RES CHIP JUMPER
JU505 - - - - - - - - - NOTPLACED
JU507 0611077A01 RES CHIP JUMPER
JU508 thru
JU511
- - - - - - - - - NOTPLACED
JU512 0611077A01 RES CHIP JUMPER
JU513 - - - - - - - - -
0611077A01
NOTPLACED
1, 2, and 3
RES CHIP JUMPER
4 and 5
JU514 0611077A01 RES CHIP JUMPER
JU515 thru
JU517
- - - - - - - - - NOTPLACED
JU518 0611077A01
- - - - - - - - -
RES CHIP JUMPER
1, 2,
and 3
NOTPLACED
4 and 5
JU519 0611077A01
- - - - - - - - -
RES CHIP JUMPER
1, 2, 3,
and 5
NOTPLACED
4
JU520 0611077A01 RES CHIP JUMPER
JU521 0611077A01
- - - - - - - - -
RES CHIP JUMPER
1, 2,
and 3
NOTPLACED
4 and 5
JU523 thru
JU527
0611077A01 RES CHIP JUMPER
JU528 - - - - - - - - -
0611077A01
NOTPLACED
1, 2, 3, and 5
RES CHIP JUMPER
4
JU529 thru
JU531
0611077A01 RES CHIP JUMPER
JU532 - - - - - - - - - NOTPLACED
JU533 0611077A01 RES CHIP JUMPER
JU534,
JU535
- - - - - - - - - NOTPLACED
JU536 0611077A01 RES CHIP JUMPER
JU537 - - - - - - - - - NOTPLACED
JU538 0611077A01 RES CHIP JUMPER
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
JU601 - - - - - - - - - NOTPLACED
L500 & L506 2480067M01 CHK RF CHIP BEAD
INDUCTOR 28MZ
L511 2413924A13 IND CHIP 10.0 UH 10%
L528 2480067M01 CHK RF CHIP BEAD
INDUCTOR 28MZ
P501 2805515W01 CONN PLUG
P502 0980103M02 RECEPTACLE RIGHT
ANGLE
P503 2880267M01 PLUG RIGHT ANGLE HDR
26 POS
Q400 4880141L01 TSTR PNP SOT23 LO
PROFILE TAPE
Q401 4880048M01 TSTR NPN DIG 47K/47K
Q402 4880141L01 TSTR PNP SOT23 LO
PROFILE TAPE
Q403 &
Q404
4880048M01 TSTR NPN DIG 47K/47K
Q500 4813822D39 TSTR PNP 60V 7A 2N5194
Q501 4880053M02 TSTR NPN MXT2222A
Q502 4880182D46 TSTR NPN 2N5190
Q503 4880141L02 TSTR NPN SOT23 LO
PROFILE TAPE
Q504 &
Q506
4805128M27 TSTR SOT89 BSR33 LH
Q507 4880048M01 TSTR NPN DIG 47K/47K
Q508 4805218N50 TSTR SOT BCW 60B (RH)
Q509 4805128M12 TSTR SOT BCW 60B (RH)
Q510 4880048M01 TSTR NPN DIG 47K/47K
Q511 4880141L01 TSTR PNP SOT23 LO
PROFILE TAPE
Q512 - - - - - - - - - NOTPLACED
Q513 thru
Q515
4880048M01 TSTR NPN DIG 47K/47K
Q516 &
Q517
- - - - - - - - - NOTPLACED
Q520 4880048M01 TSTR NPN DIG 47K/47K
Q521 4880182D46 TSTR NPN 2N5190
Q538 4880048M01 TSTR NPN DIG 47K/47K
Q540 thru
Q543
4880048M01 TSTR NPN DIG 47K/47K
Q554 4880048M01 TSTR NPN DIG 47K/47K
Q555 4805218N11 XISTOR SOT RH BST82
Q601 &
Q602
4880141L01 TSTR PNP SOT23 LO
PROFILE TAPE
Q603 4805128M12 TSTR SOT BCW 60B (RH)
2, 3, 4, and 5
R400 0611077B03 RES CHIP 15K 5 1/8W
R401 & R402 0611077B25 RES CHIP 120K 5 1/8W
R403 & R404 0611077B15 RES CHIP 47K 5 1/8W
R405 & R406 0611077A82 RES CHIP 2200 5 1/8
R407 & R408 0611077B15 RES CHIP 47K 5 1/8W
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
R409 & R410 0611077B11 RES CHIP 33K 5 1/8W
R411 & R412 0611077B15 RES CHIP 47K 5 1/8W
R413 0611077B23 RES CHIP 100K 5 1/8W
R414 0611077A74 RES CHIP 1000 5 1/8
R415 0611077A68 RES CHIP 560 5 1/8W
R416 0611077B15 RES CHIP 47K 5 1/8W
R417 & R418 0611077A98 RES CHIP 10K 5 1/8W
R419 0611077B23 RES CHIP 100K 5 1/8W
R420 0611077B03 RES CHIP 15K 5 1/8W
R421 0611077B07 RES CHIP 22K 5 1/8W
R422 0611077B20 RES CHIP 75K 5 1/8W
R423 0611077A68 RES CHIP 560 5 1/8W
R424 & R425 0611077A74 RES CHIP 1000 5 1/8
R426 & R427 0611077A98 RES CHIP 10K 5 1/8W
R428 & R429 0611077A74 RES CHIP 1000 5 1/8
R437 0611077B15 RES CHIP 47K 5 1/8W
R438 & R439 0611077B03 RES CHIP 15K 5 1/8W
R440 0611077B23 RES CHIP 100K 5 1/8W
R441 0611077A90 RES CHIP 4700 5 1/8
R442 0611077A98 RES CHIP 10K 5 1/8W
R443 0611077A95 RES CHIP 7500 5 1/8
R454 0611077B23 RES CHIP 100K 5 1/8W
R455 0611077A98 RES CHIP 10K 5 1/8W
R456 0611077B11 RES CHIP 33K 5 1/8W
R457 & R458 0611077A10 RES CHIP 2.2 5 1/8W
R459 - - - - - - - - - NOTPLACED
R500 0611077A46 RES CHIP 68 5 1/8W
R501 0611077A58 RES CHIP 220 5 1/8W
R502 0611077A10 RES CHIP 2.2 5 1/8W
R503 0611077A98 RES CHIP 10K 5 1/8W
R504 0611077A74 RES CHIP 1000 5 1/8
R505 & R506 0611077A58 RES CHIP 220 5 1/8W
R507 0611077B15 RES CHIP 47K 5 1/8W
R508 & R509 0611077B19 RES CHIP 68K 5 1/8W
R510 0611077A98 RES CHIP 10K 5 1/8W
R511 0611077A74 RES CHIP 1000 5 1/8
R512 0611077A58 RES CHIP 220 5 1/8W
R513 0611077A50 RES CHIP 100 5 1/8W
R514 0611077A68 RES CHIP 560 5 1/8W
R515 0611077A74 RES CHIP 1000 5 1/8
R516 0611077B23 RES CHIP 100K 5 1/8W
R517 0611077A10 RES CHIP 2.2 5 1/8W
R518 0611077A74 RES CHIP 1000 5 1/8
R519 0611077B15 RES CHIP 47K 5 1/8W
R521 0611077A74 RES CHIP 1000 5 1/8
R522 0611077A78 RES CHIP 1500 5 1/8
R523 0611077A82 RES CHIP 2200 5 1/8
R524 0611077A98 RES CHIP 10K 5 1/8W
R525 0611077A50 RES CHIP 100 5 1/8W
R526 0611077B07 RES CHIP 22K 5 1/8W
R527 0611077B15 RES CHIP 47K 5 1/8W
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
