Motorola ASTRO Digital Spectra Service Manual

6881076C25-D October 28, 2002
Model Numbering, Charts, and Specifications xxxv
ASTRO Digital Spectra Plus UHF 20–40 Watt Model Chart
Model Number Description
D04QKH9SW3AN Model W3 (403-433 MHz), 20-40 Watt, 512 Channels
D04QKF9SW4AN Model W4 (403-433 MHz), 20-40 Watt, 512 Channels
D04QKF9SW5AN Model W5 (403-433 MHz), 20-40 Watt, 512 Channels
D04QKH9SW7AN Model W7 (403-433 MHz), 20-40 Watt, 512 Channels
T04QKH9SW9AN Model W9 (403-433 MHz), 20-40 Watt, 512 Channels
D04RKH9SW3AN Model W3 (450-482 MHz), 20-40 Watt, 512 Channels
D04RKF9SW4AN Model W4 (450-482 MHz), 20-40 Watt, 512 Channels
D04RKF9SW5AN Model W5 (450-482 MHz), 20-40 Watt, 512 Channels
D04RKH9SW7AN Model W7 (450-482 MHz), 20-40 Watt, 512 Channels
T04RKH9SW9AN Model W9 (450-482 MHz), 20-40 Watt, 512 Channels
Item No. Description
X XXXX HRE6001_ Receiver F/E, Range 1
XXXXX HRE6003_ Receiver F/E, Range 3
X
XXXXXXXXX HRN6020_ RF Board
X XXXX HLE6045_ VCO Carrier, Range 1
XXXXX HLE6000_ VCO Carrier, Range 3
X
XXXX HLE6101_ VCO Hybrid Kit, Range 1
XXXXX HLE6103_ VCO Hybrid Kit, Range 3
X
XXXXXXXXX HLN5558_ Command Board Kit
X
XXXXXXXXX HLN6837_ VOCODER Controller
X
XXXX HLE6049_ Power Amplifier, 40W, Range 1
XXXXX HLE6043_ Power Amplifier, 40W, Range 3
X X HLN6344_ Interface Board
XXX X XX HLN6401_ Control Head Interconnect Board
X
X HLN6459_ W3 Interface Board
X
X HMN4044_ ASTRO Handheld Control Head (W3)
X X AAHN4045_ Control Head Assembly (W4)
X X XX HLN6396_ Control Head Deck Compatible
X X HCN1078_ W9 Control Head
O
OOOOOOOOO NTN9801_ UCM, ASTRO Spectra Plus
XXX X XX HMN1080_ Microphone
X X HMN1061_ Microphone
X
XXXXXXXXX HSN4018_ Speaker
X X HLN4921_ Trunnion
X X HLN5488_ Installation Hardware
X X HLN6185_* Remote-Mount, SECURENET Control-Head Hardware
X
XXX XXXX HLN6015_ Trunnion/Hardware (Dash Mount)
X
XXX XXXX HLN6073_ Dash-Mount Hardware
X
XXXXXXXXX HLN6418_* Transceiver Hardware
X X HLN6440_* Control Head without Keypad Hardware
X X HLN6441_* Control Head with Keypad Hardware
X X HLN6493_* Plug Kit
X X HLN4952_ Fuse Kit
X
XXX XXXX HKN4191_ Power Cable (Length - 20 Feet)
X X HKN4192_ Power Cable (Length - 20 Feet)
X X HKN4356_ Radio Cable (Length - 17 Feet)
X X HLN6481_* Systems 9000 E9 Clear Button Kit
X X HLN6549_* C4 Button Kit
X = Item Included
O = Optional
_ = the latest version kit. When ordering a kit, refer to your specific kit for the suffix number.
* = kit not available. Order piece parts from the
Customer Care and Services Division.
