Motorola ASTRO Digital Spectra Service Manual

6881076C25-D October 28, 2002
Model Numbering, Charts, and Specifications xxxvii
ASTRO Digital Spectra Plus UHF 50–110 Watt Model Chart
Model Number Description
T04QLH9SW3AN Model W3 (403-433 MHz), 50-110 Watt, 512 Channels
T04QLF9SW4AN Model W4 (403-433 MHz), 50-110 Watt, 512 Channels
T04QLF9SW5AN Model W5 (403-433 MHz), 50-110 Watt, 512 Channels
T04QLH9SW7AN Model W7 (403-433 MHz), 50-110 Watt, 512 Channels
T04QLH9SW9AN Model W9 (403-433 MHz), 50-110 Watt, 512 Channels
T04RLH9SW3AN Model W3 (450-482 MHz), 50-110 Watt, 512 Channels
T04RLF9SW4AN Model W4 (450-482 MHz), 50-110 Watt, 512 Channels
T04RLF9SW5AN Model W5 (450-482 MHz), 50-110 Watt, 512 Channels
T04RLH9SW7AN Model W7 (450-482 MHz), 50-110 Watt, 512 Channels
T04RLH9SW9AN Model W9 (450-482 MHz), 50-110 Watt, 512 Channels
T04SLH9SW3AN Model W3 (482-512 MHz), 50-110 Watt, 512 Channels
T04SLF9SW4AN Model W4 (482-512 MHz), 50-110 Watt, 512 Channels
T04SLF9SW5AN Model W5 (482-512 MHz), 50-110 Watt, 512 Channels
T04SLH9SW7AN Model W7 (482-512 MHz), 50-110 Watt, 512 Channels
T04SLH9SW9AN Model W9 (482-512 MHz), 50-110 Watt, 512 Channels
Item No. Description
XXXXX HRE6001_ Board, RX Front-End, Range 1
XXXXX HRE6003_ Board, RX Front-End, Range 3
X XXXX HRE6004_ Board, RX Front-End, Range 4
XX
XXXXXXXXXXXXX HRN6020_ RF Board
XX
XXX HLE6045_ VCO Carrier, Range 1
XXXXX HLE6039_ VCO Carrier, Range 3
X XXXX HLE6041_ VCO Carrier, Range 4
XX
XXX HLE6101_ VCO Hybrid Kit, Range 1
XXXXX HLE6103_ VCO Hybrid Kit, Range 3
X XXXX HLE6104_ VCO Hybrid Kit, Range 4
XX
XXXXXXXXXXXXX HLN5558_ Command Board Kit
XX
XXXXXXXXXXXXX HLN6837_ VOCON Board Kit
XX
XXX HLE6051_ Power Amplifier Board, 100W, Range 1
XXXXX HLE6099_ Power Amplifier Board, Range 3
X XXXX HLE6040_ Power Amplifier Board, Range 4
X
XXX XXXX XXXX HLN6486_ Interconnect Board
X
X X HLN6574_ W3 Interconnect Board
X
XX XXX XXX HLN6432_ Back Housing, Control Head
X
X X HMN4044_ W3 Handheld Control Head
X X X AAHN4045_ Control Head Assembly (W4)
XX X X XX HLN6396_ W5, W7 Control Head Board
X X X HCN1078_ W9 Control Head
OO
OOOOOOOOOOOOO NTN9801_ UCM, ASTRO Spectra Plus
X
XX XXX XXX HMN1080_ Microphone
X X X HMN1061_ Microphone
XX
XXXXXXXXXXXXX HSN6001_ Speaker
X X X HLN4921_ Control Head (W9) Trunnion
O O O HLN5488_ Radio Microphone Installation Hardware
X XX XXX XXX HLN6231_ Remote W4, W5, W7 Control-Head Trunnion
XX
XXXXXXXXXXXXX HLN6233_* Option Connector Hardware
XX
XXXXXXXXXXXXX HLN6132_* Installation Hardware, High-Power
X X X HLN6291_ Installation Hardware Kit
XX
XXXXXXXXXXXXX HLN6121_* High-Power Radio Hardware
XX
XXXXXXXXXXXXX HLN6525_* High-Power Transceiver Hardware
X = Item Included
O = Optional
_ = the latest version kit. When ordering a kit, refer to your specific kit for the suffix number.
* = kit not available. Order piece parts from the Customer Care and Services Division.
